DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 113
DCA-220SSK — ENGINE OPERATING PANEL ASSY. (OPTIONAL PARTS)
ENGINE OPERATING PANEL ASSY. (OPTIONAL PARTS WITH SLOW DOWN) UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
33 020108060 HEX. NUT ................................................. 2 .........REPLACES 0030008000
34 0207006000 HEX. NUT 2
35 0802100704 PIN BOLT 1
36 0207006000 HEX. NUT 1
37 031108160 PLAIN WASHER ....................................... 3 .........REPLACES 0041608000
38 952404470 PLAIN WASHER ....................................... 1 .........REPLACES 0041606000
39 0605010503 SNAP PIN 1
40 1819001931 CONTROLLER ......................................... 1 .........REPLACES 0602210803
41 8182159304 BRACKET 1
42 0027106012 MACHINE SCREW 3
43 011008020 HEX. HEAD BOLT .................................... 4 .........REPLACES 0017108020
44 0601802133 FUSE ........................................................ 1 .........F-5 5A
45 0802100204 JOINT 1
46 0802101204 SPRING 1
47 8182159103 BRACKET 1
48 011208030 HEX. HEAD BOLT .................................... 2 .........REPLACES 0017108030
49 0021005020 MACHINE SCREW 1
0032005000 LOCK WASHER ....................................... 1 .........REPLACES 0040005000
0041205000 PLAIN WASHER 1
50 0601820995 RELAY ...................................................... 2 .........JA1C-TM DC24
51 0027105010 MACHINE SCREW 4
52 0601822560 BUZZER ................................................... 1 .........BA-047
53 0027105010 MACHINE SCREW 1
54 0601820067 RECTIFIER .............................................. 1 .........PB2510
55 0021005020 MACHINE SCREW 1
0032005000 LOCK WASHER ....................................... 1 .........REPLACES 0040005000
58151 PLAIN WASHER ....................................... 1 .........REPLACES 0041205000
56 08002323306 SLOW DOWN UNIT 1
57 8182630104 BRACKET 1
58 0027105010 MACHINE SCREW 6
59 011206020 HEX. HEAD BOLT .................................... 4 .........REPLACES 0017106020
60 6008151252 EMERGENCY RELAY .............................. 1 .........REPLACES 0602200446
61 0017106016 HEX. HEAD BOLT 4
62 0602201910 UNIT, BATTERY SENSOR ....................... 1 ......... C703900000
63 0027106016 MACHINE SCREW 1
64 0601821370 RECTIFIER;DE4503 ................................. 2 ......... REPLACES 0601823240
65 0021005035 MACHINE SCREW 1
0032005000 LOCK WASHER ....................................... 1 .........REPLACES 0040005000
58151 PLAIN WASHER ....................................... 1 .........REPLACES 0041205000
66 8182210113 COVER, ELECTRIC PARTS 1
67 0017106016 HEX. HEAD BOLT 1
68 8181860103 SET BOARD, OUTPUT TERMINAL 1
69 0801830304 OUTPUT TERMINAL 7
