DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 127
DCA-220SSK — BATTERY ASSY.
BATTERY ASSY.
NO PART NO PART NAME QTY. REMARKS
1 0165614551 BATTERY ................................... 2 ......... 145G51 12V-150 Ah
2 0805000804 BATTERY SHEET 2
3 0805000904 BATTERY BAND 2
4 0805002904 BATTERY BOLT 4
5 0037808000 WING NUT 4
6 0040008000 LOCK WASHER 4
7 031108160 PLAIN WASHER ........................ 4 ......... REPLACES 0041608000
8 8182280304 BATTERY CABLE ...................... 1 ......... UP TO S/N1337562
C1347600004 BATTERY CABLE ...................... 1 ......... S/N1337563~
9 8182280104 BATTERY CABLE ...................... 1 ......... UP TO S/N1337562
C1347600104 BATTERY CABLE ...................... 1 ......... S/N1337563~
10 8182280504 BATTERY CABLE ...................... 1 ......... UP TO S/N1337562
C1347600504 BATTERY CABLE ...................... 1 ......... S/N1337563~
11 8182280704 BATTERY CABLE ...................... 1 ......... UP TO S/N1337562
C1347600304 BATTERY CABLE ...................... 1 ......... S/N1337563~
12 8182280904 EARTH CABLE .......................... 1 ......... UP TO S/N1337562
C1347200104 EARTH CABLE .......................... 1 ......... S/N1337563~
13 012010030 HEX. HEAD BOLT ...................... 4 ......... REPLACES 0010010030
14 020310080 HEX. NUT .................................. 4 ......... REPLACES 0030010000
15 0017110025 HEX. HEAD BOLT ...................... 1 ......... UP TO S/N1337562
0010110020 HEX. HEAD BOLT ...................... 1 ......... S/N1337563~
0040010000 LOCK WASHER ......................... 1 ......... S/N1337563~
004161000 PLAIN WASHER ........................ 1 ......... S/N1337563~
16 0040510000 TOOTHED WASHER 1
17 0845040414 TERMINAL CAP (+) 2
18 0845041304 TERMINAL CAP (-) 2
19 0602220203 BATTERY SENSOR ................... 1 ......... REPLACES 0602220204;
