DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 139
ENCLOSURE ASSY. UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
DCA-220SSK — ENCLOSURE ASSY.
8185172103 SIDE PANEL 1
8185102403 LINING 1
50 8185172003 SIDE PANEL 1
8185172013 SIDE PANEL 1
8185102303 LINING 1
51 0019108065 HEX. HEAD BOLT 4
030208200 LOCK WASHER ......................... 4 ................... REPLACES 0042308000
031108160 PLAIN WASHER ........................ 4 ................... REPLACES 0042408000
52 8185176204 GUIDE PANEL, AIR 2
8185103504 LINING 2
53 8185176104 GUIDE PANEL, AIR 1
8185103404 LINING 1
54 011008020 HEX. HEAD BOLT ...................... 16 .................. REPLACES 0017108020
55 8185171103 SIDE DOOR 1
8185171113 SIDE DOOR 1
8185103803 LINING 1
56 8185171003 SIDE DOOR 1
8185171013 SIDE DOOR 1
8185102203 LINING 1
57 8185171303 SIDE DOOR 1
8185171313 SIDE DOOR 1
8185103204 LINING 1
58 8185171203 SIDE DOOR 1
8185171213 SIDE DOOR 1
8185102503 LINING 1
59 0845033304 DOOR HANDLE 7
60 0845034204 DOOR LATCH 4
61 0845034104 DOOR LATCH 3
62 011008020 HEX. HEAD BOLT ...................... 7 ................... REPLACES 0019208020
63 0810009103 HINGE 8
0845046904 HINGE 8
63-1 0845045004 WASHER 8
64 0810009203 HINGE 8
0845047004 HINGE 8
64-1 0845045004 WASHER 8
65 011008020 HEX. HEAD BOLT ...................... 48 .................. REPLACES 0019208020
66 8185176004 GUIDE PANEL, AIR 2
8185103304 LINING 2
67 8185176304 GUIDE PANEL, AIR 1
8185103604 LINING 1
68 011008020 HEX. HEAD BOLT ...................... 22 .................. REPLACES 0017108020
69 0845031504 CAP 20
70 0194500700 HOSE 1
71 0605515003 HOSE BAND 2
72 0800517103 EMBLEM 2
73 0021106020 MACHINE SCREW 4
