DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 123
DCA-220SSK — OUTPUT TERMINAL ASSY.
OUTPUT TERMINAL ASSY. S/N3690735~
NO PART NO PART NAME QTY. REMARKS
1 C1231700003 SET BOARD, OUTPUT TERMINAL 1
2 0801030304 OUTPUT TERMINAL 8
3 0801830804 HEX. HEAD BOLT 8
4 0039316000 HEX. NUT 16
5 0040016000 LOCK WASHER 24
6 0041416000 PLAIN WASHER 32
7 3461860504 TERMINAL PLATE 3
8 0019108040 HEX. HEAD BOLT 5
0205008000 HEX. NUT 5
0042308000 LOCK WASHER 10
0042408000 PLAIN WASHER 10
9 0601805313 CIRCUIT BREAKER ........................................ 2 ........ KM51B 265V 20
10 0601805840 CIRCUIT BREAKER ........................................ 3 ........ KM52 265V 50A
11 C1261600204 BRACKET, CIRCUIT BREAKER 1
12 0017106020 HEX. HEAD BOLT 2
13 0601812598 RECEPTACLE ................................................. 2 ........ GF530EM
14 0601812565 RECEPTACLE ................................................. 3 ........ CS6369
15 0027104015 MACHINE SCREW 10
0030004000 HEX. NUT 10
0041204000 PLAIN WASHER 10
16 C1237100113 COVER, OUTPUT TERMINAL 1
17 0019112045 HEX. HEAD BOLT 2
18 0042412000 PLAIN WASHER 2
19 0805015604 STAY RUBBER 2
20 0205012000 HEX. NUT 2
21 0845043704 SPRING 2
22 C1237100214 COVER 1
23 0017108020 HEX. HEAD BOLT 7
24 C0237101504 COVER, OUTPUT TERMINAL 1
25 0805015604 STAY RUBBER 1
26 0845054204 COLLAR 2
27 0017110040 HEX. HEAD BOLT 2
28 0601815324 TERMINAL BOARD;TS22P ............................. 1 ........ S/N3696501~
29 0027104020 MACHINE SCREW .......................................... 2 ........ S/N3696501~
30 0601850275 GROMMET ...................................................... 1 ........ S/N3696501~
31 0601851780 GROMMET ...................................................... 2 ........ S/N3700671~
