DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 117
DCA-220SSK — ENGINE OPERATING PANEL ASSY.
ENGINE OPERATING PANEL ASSY. S/N1337563~
NO PART NO PART NAME QTY. REMARKS
1 C1352101103 OPERATING PANEL ....................... 1 .......... UP TOS/N3696500
1 C1352101113 OPERATING PANEL ....................... 1 .......... S/N3696501 TO3701661
1 C1352101123 OPERATING PANEL ....................... 1 .......... S/N3701662~
2 0019106016 HEX. HEAD BOLT 12
0042306000 LOCK WASHER 12
0042406000 PLAIN WASHER 12
3 0602101000 BATTERY SWITCH ......................... 1 .......... 9827300090
4 0021008080 MACHINE SCREW 2
0030008000 HEX. NUT 2
0040008000 LOCK WASHER 2
0041608000 PLAIN WASHER 4
5 0800250300 THROTTLE HANDLE ...................... 1 .......... UP TO 3701661
6 6008155390 STARTER SWITCH ......................... 1 .......... UP TO S/N3696500;REPLACES 0602100049
6 0601830448 PREHEAT BUTTON ........................ 1 .......... S/N3696501~;AH25FB10
7 0806410000 STOP BUTTON ............................... 1 .......... UP TO S/N3696500;REPLACES 0602104045
7 0602104045 EMERGENCY STOP BUTTON ....... 1 .......... S/N3696501 TO3701661
7 0601831557 EMERGENCY STOP BUTTON ....... 1 .......... S/N3701662~
8 6008153730 PREHEAT LAMP ............................. 1 .......... REPLACES 0602102055
9 0602120054 TACHOMETER ................................ 1 .......... 25000KX4110
10 0602120175 CABLE, TACHOMETER .................. 1 .......... 62100KX0700
11 0602122060 OIL PRESSURE GAUGE ................ 1 .......... 42000KX1410
12 0602122200 UNIT, OIL PRESSURE .................... 1 .......... 53000AC0101
13 0602123061 WATER TEMPERATURE GAUGE ... 1 .......... 40000KX0910
14 0602123206 UNIT, WATER TEMPERATURE ....... 1 .......... 51400KS0600
15 0602121052 CHARGINE AMMETER .................. 1 .......... 43000KV0300
16 0602125060 FUEL GAUGE ................................. 1 .......... 41000KW0110
17 0602115014 MONITOR ....................................... 1 .......... V337660
18 C1484000202 SUPPORT LEG .............................. 1 .......... UP TO S/N3701661
18 C1484000212 SUPPORT LEG .............................. 1 .......... S/N3701662~
19 0010110030 HEX. HEAD BOLT 5
20 C1355100104 LINK, GOVERNOR ROD ................. 1 .......... UP TO S/N3701661
21 0010010035 HEX. HEAD BOLT ........................... 1 .......... UP TO S/N3701661
0030010000 LOCK WASHER .............................. 1 .......... UP TO S/N3701661
0041210000 PLAIN WASHER ............................. 1 .......... UP TO S/N3701661
