DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 135
ENCLOSURE ASSY. UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
1 8185111002 BASE 1
8185111012 BASE 1
2 8185116004 FLOOR PANEL 1
3 011008020 HEX. HEAD BOLT .............................. 12 ......... REPLACES 0019208020
4 8185121002 FRONT FRAME 1
8185121012 FRONT FRAME 1
8185102003 LINING 1
5 0019110025 HEX. HEAD BOLT 8
0042310000 LOCK WASHER 8
0042410000 PLAIN WASHER 8
6 8185125104 COVER, FRONT FRAME 1
8185102604 LINING 1
7 011008020 HEX. HEAD BOLT .............................. 19 ......... REPLACES 0019208020
8 0845042703 FILLER BRACKET 1
9 011008020 HEX. HEAD BOLT .............................. 4 ........... REPLACES 0019208020
10 8185125003 COVER, FRONT FRAME 1
8185125013 COVER, FRONT FRAME 1
11 011008020 HEX. HEAD BOLT .............................. 12 ......... REPLACES 0019208020
12 8185131002 CENTER FRAME 1
8185131012 CENTER FRAME 1
13 0019114050 HEX. HEAD BOLT 4
0205014000 HEX. NUT 4
0042314000 LOCK WASHER 4
0042414000 PLAIN WASHER 8
14 0019114040 HEX. HEAD BOLT 8
0205014000 HEX. NUT 8
0042314000 LOCK WASHER 8
0042414000 PLAIN WASHER 16
15 8185141002 REAR FRAME 1
8185141012 REAR FRAME 1
8185102704 LINING 1
16 0019110025 HEX. HEAD BOLT 4
0042310000 LOCK WASHER 4
0042410000 PLAIN WASHER 4
17 8185155003 COVER, REAR FRAME 1
8185102804 LINING 1
18 01108020 HEX. HEAD BOLT .............................. 17 ......... REPLACES 0019208020
19 8185155104 GUIDE PANEL, AIR 1
8185102904 LINING 1
20 01108020 HEX. HEAD BOLT .............................. 12 ......... REPLACES 0017108020
21 8185118504 GUIDE PANEL, AIR 1
8185103004 LINING 1
22 01108020 HEX. HEAD BOLT .............................. 4 ........... REPLACES 0017108020
23 8185143103 DOOR, REAR FRAME 1
8185143113 DOOR, REAR FRAME 1
DCA-220SSK — ENCLOSURE ASSY.
