DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 115
DCA-220SSK — ENGINE OPERATING PANEL ASSY. (OPTIONAL PARTS)
ENGINE OPERATING PANEL ASSY. (OPTIONAL PARTS WITH SLOW DOWN) UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
70 0801830804 HEX. HEAD BOLT 7
71 0039316000 HEX. NUT 14
72 0040016000 LOCK WASHER 21
73 0041416000 PLAIN WASHER 28
74 3461860504 TERMINAL PLATE 3
75 0801832304 TERMINAL SCREW 1
76 0039306000 HEX. NUT 5
77 0040006000 LOCK WASHER 6
78 952404470 PLAIN WASHER ....................................... 6 .........REPLACES 0041606000
79 011208030 HEX. HEAD BOLT .................................... 5 .........REPLACES 0010008030
0040008000 LOCK WASHER 5
031108160 PLAIN WASHER ....................................... 5 .........REPLACES 0041608000
80 0601812597 RECEPTACLE, AUX. POWER;1136X ...... 1 .........REPLACES 0601811018
81 0025004016 MACHINE SCREW 2
0042304000 LOCK WASHER 2
0042404000 PLAIN WASHER 2
82 0601802010 CIRCUIT BREAKER ................................. 1 .........KM-2 220V 15A
83 0845032304 BRACKET, CIRCUIT BREAKER 1
83-1 0223300060 RUBBER CUSHION 1
84 0019106020 HEX. HEAD BOLT 4
0042306000 LOCK WASHER 4
0042406000 PLAIN WASHER 4
85 0601811262 RECEPTACLE REMOTE CONTROL ........ 1 ......... NCS-4410-RF
86 0601811409 CAP, RECEPTACLE ................................. 1 ......... NCS-44-RCa
87 0027103010 MACHINE SCREW ................................... 3 .........REPLACES 0021103010
88 0025013010 MACHINE SCREW 3
0042303000 LOCK WASHER 3
0042403000 PLAIN WASHER 3
89 8185182003 COVER, OUTPUT TERMINAL 1
90 0019112045 HEX. HEAD BOLT 2
91 0042412000 PLAIN WASHER 4
92 0805009804 RUBBER WASHER 2
93 0205012000 HEX. NUT 2
94 0845043704 SPRING 2
95 0040506000 TOOTHED WASHER 1
96 011206020 HEX. HEAD BOLT .................................... 1 .........REPLACES 0017106020
97 0840300803 CURRENT TRANSFORMER 2
