DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 111
DCA-220SSK — ENGINE OPERATING PANEL ASSY. (OPTIONAL PARTS)
ENGINE OPERATING PANEL ASSY. (OPTIONAL PARTS WITH SLOW DOWN)- UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
1 8182111003 OPERATING PANEL 1
2 0017106016 HEX. HEAD BOLT 12
3 0602101000 BATTERY SWITCH ........................................... 1 ....... 9827300090
4 0021008080 MACHINE SCREW 2
020108060 HEX. NUT .......................................................... 2 ....... REPLACES 0030008000
0040008000 LOCK WASHER 2
031108160 PLAIN WASHER ................................................ 4 ....... REPLACES 0041608000
5 0800250300 THROTTLE HANDLE 1
6 6008155390 STARTER SWITCH ........................................... 1 ....... REPLACES 0602100049
7 0806410000 EMERGENCY STOP BUTTON ......................... 1 ....... REPLACES 0602104045
8 6008153730 PREHEAT LAMP ............................................... 1 ....... REPLACES 0602102055
9 0602120054 TACHOMETER;25000KX3710 ........................... 1 ....... REPLACES 0602120052
10 0602120178 CABLE, TACHOMETER .................................... 1 ....... 62100KX0700
11 0602122053 OIL PRESSURE GAUGE .................................. 1 ....... 42000KV0300
12 0602122200 UNIT, OIL PRESSURE ...................................... 1 ....... 53000AC0101
13 0602123053 WATER TEMPERATURE GAUGE ..................... 1 ....... 40000KV0700
14 0602123204 UNIT, WATER TEMPERATURE ......................... 1 ....... 51400KA1200
15 0602121052 CHARGING AMMETER .................................... 1 ....... 43000KV0300
16 0602040690 INDICATOR, AIR CLEANER .............................. 1 ....... RBX002252
17 0603300000 HALF UNION, PT 1/8 x 4 1
18 0603302000 SLEEVE 1
19 0603303000 NUT 1
20 0190001000 NYLON PIPE 1
21 0602115008 ENGINE WARNING DISPLAY LED ................... 1 ....... V 336760
0601810204 BULB 6
22 0601830707 SWITCH, SLOW DOWN .................................... 1 ....... S-331T
23 0601830683 SELECTOR SWITCH, REMOTE CONTROL ..... 1 ....... AH30P2B33
24 0601831200 REMOVE BUTTON, IDLING .............................. 1 ....... MB201110K
25 0602103091 PILOT LAMP, IDLING ........................................ 1 ....... REPLACES 0602103090
0601810244 BULB 1
26 8185312002 SUPPORT LEG 1
27 012010030 HEX. HEAD BOLT ............................................. 5 ....... REPLACES 0010010030
020310080 HEX. NUT .......................................................... 2 ....... REPLACES 0030010000
0040010000 LOCK WASHER 5
031110160 PLAIN WASHER ................................................ 7 ....... REPLACES 0041610000
28 8192183004 LINK, GOVERNOR ROD 1
29 0010010055 HEX. HEAD BOLT 1
020310080 HEX. NUT .......................................................... 1 ....... REPLACES 0030010000
031110160 PLAIN WASHER ................................................ 2 ....... REPLACES 0041610000
30 8182152004 GOVERNOR ROD 1
31 8182152104 GOVERNOR ROD 1
32 0602180106 BALL JOINT 2
