DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 83
DCA-220SSK — CONTROL BOX ASSY. (OPTIONAL PARTS)
CONTROL BOX ASSY. (OPTIONAL PARTS) UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
1 8181812502 CONTROL BOX 1
2 0601801167 CURRENT TRANSFORMER, AMMETER ... 2 ........ CT5MR 440/5A
3 0027106010 MACHINE SCREW 4
4 0601805950 CIRCUIT BREAKER .................................... 1 ........ TO600CA 600A
5 0601820625 AUTOMATIC VOLTAGE REGULATOR ......... 1 ........ NTA-5A-27
6 0027105012 MACHINE SCREW 4
7 0601820193 CONDENSER .............................................. 1 ........ 40FAL155U #L2
8 0027103010 MACHINE SCREW 2
9 0601820851 OVER CURRENT RELAY ............................ 1 ......THK20
10 0027104016 MACHINE SCREW 2
11 0601823757 RELAY ......................................................... 2 ........ MY2DC24V
12 0601823143 SOCKET, RELAY ........................................ 2 ........ PYF08A
PYCA1 HOLDER ...................................................... 2 ........ REPLACES 0601824400
13 0027104016 MACHINE SCREW 4
14 0601821370 RECTIFIER ................................................. 1 ........ DE4503 REPLACES 0601823240
15 0027105016 MACHINE SCREW 1
16 0801850004 RESISTOR UNIT 1
17 0021005020 MACHINE SCREW 1
0032005000 LOCK WASHER .......................................... 1 ........ REPLACES 0040005000
0401450050 PLAIN WASHER .......................................... 1 ........ REPLACES 0041205000
020106050 HEX. NUT .................................................... 1 ........ REPLACES 0030006000
18 0601830715 SELECTOR SWITCH, VOLTAGE ................. 1 ........ S332T
19 8181861103 SET BOARD, CHANGE TERMINAL 1
20 8181852104 CHANGE TERMINAL 10
21 011606025 HEX. HEAD BOLT ....................................... 20 ...... REPLACES 0017106025
22 8181853104 CHANGE PLATE 6
23 8131852504 HEX. HEAD BOLT 10
24 012210020 HEX. HEAD BOLT ....................................... 16 ...... REPLACES 0801831804
25 0040010000 LOCK WASHER 26
26 0041410000 PLAIN WASHER 26
27 011208030 HEX. HEAD BOLT ....................................... 4 ........ REPLACES 0017108030
28 8181833003 SET PANEL, ELECTRIC PARTS 1
29 011008020 HEX. HEAD BOLT ....................................... 4 ........ REPLACES 0017108020
30 0601823704 REVERSE POWER RELAY 1
31 0027104010 MACHINE SCREW 4
32 8181822603 CONTROL PANEL 1
33 8181822503 CONTROL PANEL 1
33-1 0225100095 RUBBER SEAL 4
34 0605011211 PIN .............................................................. 4 ........ B-99-2
35 0601800470 FREQUENCY METER ................................ 1 ........ PAK80 220V 45~65HZ
36 0601800790 AC AMMETER ............................................ 1 ........ PSK80 0~400A 0~800A
REPLACES 0601805726
Control Box (Options) up to S/N1337562
