DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 107
ENGINE OPERATING AND OUTPUT TERMINAL ASSY. UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
33 0802100704 PIN BOLT 1
34 0207006000 HEX. NUT 1
35 031108160 PLAIN WASHER ....................................... 3 .........REPLACES 0041608000
36 952404470 PLAIN WASHER ....................................... 1 .........REPLACES 0041606000
37 0605010503 SNAP PIN 1
38 1819001931 CONTROLLER ......................................... 1 .........REPLACES 0602210803
39 8182159304 BRACKET 1
40 0027106012 MACHINE SCREW 3
41 011008020 HEX. HEAD BOLT .................................... 4 .........REPLACES 0017108020
42 0601802133 FUSE ........................................................ 1 .........F-5 5A
43 0802100204 JOINT 1
44 0802101204 SPRING 1
45 8182159103 BRACKET 1
46 011208030 HEX. HEAD BOLT .................................... 2 .........REPLACES 0017108030
47 0021005020 MACHINE SCREW 1
0032005000 LOCK WASHER ....................................... 1 .........REPLACES 0040005000
0041205000 PLAIN WASHER 1
48 0601823873 UNIT, AUTO, IDLING ................................ 1 .........REPLACES 0601823872
49 011606025 HEX. HEAD BOLT .................................... 2 .........REPLACES 0017106025
50 6008151252 EMERGENCY RELAY .............................. 1 .........REPLACES 0602200446
51 0017106016 HEX. HEAD BOLT 4
52 0602201910 UNIT, BATTERY SENSOR ....................... 1 ......... C703900000
53 0027106016 MACHINE SCREW 1
54 8182210113 COVER, ELECTRIC PARTS 1
55 0017106016 HEX. HEAD BOLT 1
56 8181860103 SET BOARD, OUTPUT TERMINAL 1
57 0801830304 OUTPUT TERMINAL 7
58 0801830804 HEX. HEAD BOLT 7
59 0039316000 HEX. NUT 14
60 0040016000 LOCK WASHER 21
61 0041416000 PLAIN WASHER 28
62 3461860504 TERMINAL PLATE 3
63 0801832304 TERMINAL SCREW 1
64 0039306000 HEX. NUT 5
65 0040006000 LOCK WASHER 2
66 0041406000 PLAIN WASHER 6
67 0010008030 HEX. HEAD BOLT 5
0040008000 LOCK WASHER 5
031108160 PLAIN WASHER ....................................... 5 .........REPLACES 0041608000
68 0601812597 RECEPTACLE, AUX. POWER;1136X ...... 1 .........REPLACES 0601811018
DCA-220SSK — ENGINE OPERATING AND OUTPUT TERMINAL ASSY.
