DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 89
DCA-220SSK — CONTROL BOX ASSY.
CONTROL BOX ASSY. S/N1337563~
NO. PART NO. PART NAME QTY. REMARKS
1 C1214000412 CONTROL BOX ..................................... 1 .......... S/N 1337563 TO3690734
1 C1214000422 CONTROL BOX ..................................... 1 .......... S/N3690735~
2 0601806133 TRANSFORMER, AMMETER .............. 3 .......... CT5MRN
3 0027106016 MACHINE SCREW 6
4 0601807364 CIRCUIT BREAKER ............................. 1 .......... XE600NS 600A
4-1 0601802525 HANDLE, CIRCUIT BREAKER 1
5 0601820625 AUTOMATIC VOLTAGE REGULATOR ... 1 .......... NTA5A2T
6 0027105016 MACHINE SCREW 4
7 0601820892 OVER CURRENT RELAY ...................... 1 .......... THN20HZKP3.6A
8 0027104016 MACHINE SCREW 2
9 0601824542 RELAY 2
10 0027103010 MACHINE SCREW 4
11 C1274000103 SET BOARD CHANGE TERMINAL 1
12 8181852104 CHANGE TERMINAL 10
13 0017106025 HEX. HEAD BOLT 20
14 8181853104 CHANGE PLATE 6
15 8131852504 HEX. HEAD BOLT 13
16 C0277200004 TERMINAL PLATE 3
17 0801831804 HEX. HEAD BOLT 13
18 0040010000 LOCK WASHER 26
19 0041410000 PLAIN WASHER 26
20 0017108030 HEX. HEAD BOLT 4
21 C1261500114 SET PANEL, ELECTRIC PARTS .......... 1 .......... S/N1337563 TO 3696500
21 C1261501304 SET PANEL, ELECTRIC PARTS .......... 4 .......... S/N3696501~
22 0017108020 HEX. HEAD BOLT 4
23 6008151252 EMERGENCY RELAY .......................... 1 .......... S/N3690735 TO 3701661
REPLACES0602200446
24 0017106016 HE.X HEAD BOLT ................................ 4 .......... S/N3690735 TO 3701661
25 0602201911 UNIT, BATTERY SENSOR .................... 1 .......... C7038A0000
26 0027106016 MACHINE SCREW 1
27 3871824004 STOPPER, CONTROL PANEL 1
28 0041206000 PLAIN WASHER 1
29 0605010502 SNAP PIN 1
30 C1214500004 COVER, CONTROL BOX 1
31 0017108020 HEX. HEAD BOLT 8
32 C1214300004 SIDE PANEL, CONTROL BOX 1
33 0017108020 HEX. HEAD BOLT 4
34 C1214400004 PANEL, CONTROL BOX 1
35 0017108020 HEX. HEAD BOLT 8
36 0017110025 HEX. HEAD BOLT 4
37 0601823861 STOP UNITMSA9014............................ 1 .......... S/N3696501 TO 3701661
38 0027104010 MACHINE SCREW ............................... 2 .......... S/N3696501 TO 3701661
