DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 137
ENCLOSURE ASSY. UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
DCA-220SSK — ENCLOSURE ASSY.
24 8185143003 DOOR, REAR FRAME 1
8185143013 DOOR, REAR FRAME 1
25 3515147104 WINDOW PLATE 2
26 0025006016 MACHINE SCREW 12
0205006000 HEX. NUT 12
0042306000 LOCK WASHER 12
0042406000 PLAIN WASHER 24
27 0805037204 DOOR HANDLE 1
28 0845033904 LINK, DOOR ROD 1
29 01108020 HEX. HEAD BOLT ...................... 1 ........ REPLACES 0019208020
30 8185146104 DOOR ROD 1
31 8185146004 DOOR ROD 1
32 0805011404 LOCK 1
33 0027104010 MACHINE SCREW .................... 2 ........ REPLACES 0041610000
34 031110160 PLAIN WASHER 4
35 0605010504 SNAP RING 2
36 0805011304 STOPPER, DOOR 1
37 0805011204 STOPPER, DOOR 1
38 0025006020 MACHINE SCREW 4
0205006000 HEX. NUT 4
0042306000 LOCK WASHER 4
0042406000 PLAIN WASHER 8
39 0845028203 HINGE 2
M9110100204 HINGE ........................................ 2 ........ REPLACES 0845047104
39-1 0845045004 WASHER 2
40 0845028303 HINGE 2
M9110100304 HINGE ........................................ 2 ........ REPLACES 0845047204
40-1 0845045004 WASHER 2
41 011008020 HEX. HEAD BOLT ...................... 8 ........ REPLACES 0019208020
42 8185161002 ROOF PANEL 1
8185102103 LINING 1
43 0800251701 FILLER COVER 1
44 0025006016 MACHINE SCREW 2
0042306000 LOCK WASHER 2
0042406000 PLAIN WASHER 2
45 8185161102 ROOF PANEL 1
8185103104 LINING 1
46 011008020 HEX. HEAD BOLT ...................... 40 ....... REPLACES 0019208020
47 8185181002 SPLASHER PANEL 1
8185103704 LINING 1
48 0019108065 HEX. HEAD BOLT 6
030208200 LOCK WASHER ......................... 6 ........ REPLACES 0042308000
031108160 PLAIN WASHER ........................ 6 ........ REPLACES 0042408000
49 8185172103 SIDE PANEL 1
