DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 121
DCA-220SSK — OUTPUT TERMINAL ASSY.
OUTPUT TERMINAL ASSY. S/N1337563 TO3690734
NO PART NO PART NAME QTY. REMARKS
1 C1231700003 SET BOARD, OUTPUT TERMINAL 1
2 0801030304 OUTPUT TERMINAL 8
3 0801830804 HEX. HEAD BOLT 8
4 0039316000 HEX. NUT 16
5 0040016000 LOCK WASHER 24
6 0041416000 PLAIN WASHER 32
7 3461860504 TERMINAL PLATE 3
8 0019108040 HEX. HEAD BOLT 5
0205008000 HEX. NUT 5
0042308000 LOCK WASHER 10
0042408000 PLAIN WASHER 10
9 0601812597 RECEPTACLE, AUX. POWER; 5-20R ............. 2 ........ S/N1337563 TO 1338269
10 0601811034 RECEPTACLE, AUX. POWER; C6369 ............. 3 ........ REPLACES 0601812565
11 0027104016 MACHINE SCREW 10
0030004000 HEX.NUT 10
0041204000 PLAIN WASHER 10
12 0601804887 CIRCUIT BREAKER; KM51 20A ..................... 2 ........ REPLACES 0601805313
13 0601805840 CIRCUIT BREAKER; KM52 50A 3
14 C1261600204 BRACKET, CIRCUIT BREAKER 1
14-1 0223300200 RUBBER CUSHION 1
15 0017106020 HEX. HEAD BOLT 2
16 C1237100103 COVER, OUTPUT TERMINAL 1
17 0019112045 HEX. HEAD BOLT 2
18 0042412000 PLAIN WASHER 2
19 0805009804 RUBBER WASHER 2
20 0205012000 HEX. NUT 2
21 0845043704 SPRING 2
22 C1237100204 COVER, OUTPUT TERMINAL 1
23 0017108020 HEX. HEAD BOLT 9
