DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 81
31 0601800470 FREQ. METER .................................................... 1 ...... PAK80 220V 45~65Hz
32 0601805726 AC AMMETER .................................................... 1 ...... PSK80 0~400A
33 0601801040 CHG.-OVR. SW, AMMETER ............................... 1 ...... SL2VS
34 0601800239 AC VOLTMETER ................................................. 1 ...... PCK80 0~600V
35 0601801041 CHG.-OVR.SW, VOLTMETER ............................. 1 ...... SL2AS
36 0601810072 PILOT LAMP ....................................................... 1 ...... LP132DC 220V
0601810261 BULB 1
37 0601840073 RHEOSTAT (VOLTAGE REGULATOR) ................ 1 ...... RA20A2SE102BJ
38 0601840121 KNOB 1
39 0601822408 EARTH LEAKAGE RELAY ................................. 1 ...... TZS15HCD 30mA
39-1 0601802810 0-PHASE SEQ. TRANSFORMER ....................... 1 ...... TZS15
40 0840303303 BRACKET, EARTH LEAKAGE RELAY 1
41 0021004020 MACHINE SCREW 2
0040004000 LOCK WASHER 2
0041204000 PLAIN WASHER 2
42 0027104010 MACHINE SCREW 2
43 0027104010 MACHINE SCREW 4
44 0601810072 SYNCHRONIZING LAMP .................................... 2 ...... LD132DC 220V
0601810261 BULB 2
45 0601830682 SELECTOR SW. SINGLE/PAR ............................ 1 ...... AH30P2B31
46 0601810161 PANEL LIGHT ..................................................... 1 ...... V325070
0601810214 BULB 1
47 0207004000 HEX. NUT 2
48 0601830710 SWITCH, PANEL LIGHT ..................................... 1 ...... S301T
49 7431822104 COVER 1
50 0027103016 MACHINE SCREW 4
0030003000 HEX. NUT 4
51 0805001304 SET SCREW 4
52 0041608000 PLAIN WASHER 4
53 0605010710 SNAP RING 4
54 3871824004 STOPPER, CONTROL PANEL 2
55 0041606000 PLAIN WASHER 2
56 0605010502 SNAP PIN 2
57 8181814504 COVER, CONTROL 1
58 0017106016 HEX. HEAD BOLT 13
59 8181826504 SIDE PANEL, CONTROL BOX 2
60 0017106016 HEX. HEAD BOLT 16
61 8181827503 PANEL, CONTROL BOX 1
62 0017106016 HEX. HEAD BOLT 12
63 0010010025 HEX. HEAD BOLT 4
0030010000 HEX. NUT 4
0040010000 LOCK WASHER 4
0041610000 PLAIN WASHER 8
DCA-220SSK — CONTROL BOX AND PANEL ASSY.
CONTROL PANEL ASSY. UP TO S/N1337562
NO. PART NO. PART NAME QTY. REMARKS
