DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 105
DCA-220SSK — ENGINE OPERATING AND OUTPUT TERMINAL ASSY.
ENGINE OPERATING AND OUTPUT TERMINAL ASSY. UP TO S/N1337562
NO
PART NO
PART NAME
QTY.
REMARKS
1
8182111003
OPERATING PANEL
1
8182111303
OPERATING PANEL
1
2
0017106016
HEX. HEAD BOLT
12
3
0602101000
BATTERY SWITCH .................................. 1 ......... 9827300090
4
0021008080
MACHINE SCREW
2
020108060
HEX. NUT ................................................. 2 .........REPLACES 0030008000
0040008000
LOCK WASHER
2
031108160
PLAIN WASHER ....................................... 4 .........REPLACES 0041608000
5
0800250300
THROTTLE HANDLE
1
6
6008155390
STARTER SWITCH .................................. 1 .........REPLACES 0602100049
7
0806410000
EMERGENCY STOP BUTTON ................ 1 .........REPLACES 0602104045
8
6008153730
PREHEAT LAMP ...................................... 1 .........REPLACES 0602102055
9
0602120054
TACHOMETER ......................................... 1 ......... 25000KX3710
10
0602120178
CABLE, TACHOMETER ........................... 1 .........62100KX0700
11
0602122053
OIL PRESSURE GAUGE ......................... 1 ......... 42000KV0300
12
0602122200
UNIT, OIL PRESSURE ............................. 1 .........53000AC0101
13
0602123053
WATER TEMPERATURE GAUGE ............ 1 ......... 40000KV0700
14
0602123204
UNIT, WATER TEMPERATURE ................ 1 ......... 51400KA1200
15
0602121052
CHARGING AMMETER ........................... 1 .........43000KV0300
16
0602040690
INDICATOR, AIR CLEANER ..................... 1 .........RBX002252
17
0603300000
HALF UNION, PT 1/8 x 4
1
18
0603302000
SLEEVE
1
19
0603303000
NUT
1
20
0190001000
NYLON PIPE
1
21
0602115008
ENGINE WARNING DISPLAY LED .......... 1 .........V 336760
0601810204
BULB
6
22
0602103091
CAUTION LAMP, RUNNING ..................... 1 .........REPLACES 0602103090
0601810244
BULB
1
23
0601830710
CHANGE-OVER SWITCH, AUTO/LOW .... 1 .........S/N1325370 TO 1326266;S301T
0601830685
SPEED CHANGE-OVER SWITCH ........... 1 .........S/N1326267~;AH30PCB032D
24
8185312002
SUPPORT LEG
1
25
012010030
HEX. HEAD BOLT .................................... 5 .........REPLACES 0010010030
020310080
HEX. NUT ................................................. 2 .........REPLACES 0030010000
0040010000
LOCK WASHER
5
031110160
PLAIN WASHER ....................................... 7 .........REPLACES 0041610000
26
8192183004
LINK, GOVERNOR ROD
1
27
0010010055
HEX. HEAD BOLT
1
020310080
HEX. NUT ................................................. 1 .........REPLACES 0030010000
031110160
PLAIN WASHER ....................................... 2 .........REPLACES 0041610000
28
8182152004
GOVERNOR ROD
1
29
8182152104
GOVERNOR ROD
1
30
0602180106
BALL JOINT
2
31
020108060
HEX. NUT ................................................. 2 .........REPLACES 0030008000
32
0207006000
HEX. NUT
2
Engine Op. up to S/N1337562
Eng. Op S/N1337563~
Output Term.S/N1337563 to 3690734
Output Term.S/N3690735~
