DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 85
DCA-220SSK — CONTROL BOX ASSY. (OPTIONAL PARTS)
37 0601801040 CHANGE-OVER SWITCH, AMMETER ....... 1 ........ SL2AS
38 0601800239 AC VOLTMETER ......................................... 1 ........ PCK80 0~600V
39 0601801041 CHANGE-OVER SWITCH, AMMETER ....... 1 ........ SL2 VS
40 0601800570 AC WATTMETER ......................................... 1 ........ PWTK8020~0~200kW
INCLUDE ITEM W/#
40-1# 0601804021 TRANSDUCER, WATTMETER .................... 1 ........ WT64M
41 0027104010 MACHINE SCREW 4
42 0601810072 PILOT LAMP ............................................... 1 ........ LP132DC 220V
0601810261 BULB, 13W 1
43 0601840073 RHEOSTAT (VOLTAGE REGULATOR) ......... 1 ........ RA20A2SE102BJ
44 0601840121 KNOB 1
45 0601822408 EARTH LEAKAGE RELAY .......................... 1 ........ TZS15HC-D 30mA
INCLUDE ITEM W/+
45-1+ 0601802810 ZERO-PHASE-SEQUENCE
CURRENT TRANSFORMER ....................... 1 ........ TZS-15
46 0840303303 BRACKET, EARTH LEAKAGE RELAY 1
47 021004020 MACHINE SCREW 2
040004000 LOCK WASHER 2
031104080 PLAIN WASHER .......................................... 2 ........ REPLACES 0041204000
48 0027104010 MACHINE SCREW 2
49 0027104010 MACHINE SCREW 4
50 0601810072 SYNCHRONIZING LAMP ............................ 2 ........ LD132DC 220V
0601810261 BULB, 13W 2
51 0601830682 SELECTOR SWITCH, SINGLE/PAR. .......... 1 ........ AH30P2B31
52 0601910161 PANEL LIGHT ............................................. 1 ........ V 325070
0601810214 BULB 1
53 0030004000 HEX. NUT .................................................... 2 ........ REPLACES 0207004000
54 0601830710 SWITCH, PANEL LIGHT 1
55 0805001304 SET SCREW 4
56 031108160 PLAIN WASHER .......................................... 4 ........ REPLACES 0041608000
57 0605010710 SNAP RING 4
58 3871824004 STOPPER, CONTROL PANEL 2
59 952404470 PLAIN WASHER .......................................... 2 ........ REPLACES 0041606000
60 505015300 SNAP RING ................................................ 2 ........ REPLACES 0605010502
61 8181814504 COVER, CONTROL BOX 1
62 0017106016 HEX. HEAD BOLT 13
63 8181826504 SIDE PANEL , CONTROL BOX 2
64 0017106016 HEX. HEAD BOLT 16
65 8181827503 PANEL, CONTROL BOX 1
66 0017106016 HEX. HEAD BOLT 12
67 0105091025 HEX. HEAD BOLT ....................................... 4 ........ REPLACES 0010010025
020310080 HEX. NUT .................................................... 4 ........ REPLACES 0030010000
0040010000 LOCK WASHER 4
031110160 PLAIN WASHER .......................................... 8 ........ REPLACES 0041610000
CONTROL BOX ASSY. (OPTIONAL PARTS)UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
Control Box (Options) up to S/N1337562
