DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 91
DCA-220SSK — CONTROL BOX ASSY.
CONTROL BOX ASSY. S/N1337563~
NO. PART NO. PART NAME QTY. REMARKS
39 0601823240 RECTIFIER;DE4503 ............................. 4 .......... S/N3696501 TO 3701661
40 0027104030 MACHINE SCREW ............................... 2 .......... S/N3696501 TO 3701661
41 0601802149 FUSE;10A 1
0601806671 FUSE;15A ............................................. 1 .......... S/N3701662~
0601802218 HOLDER, FUSE .................................... 1 .......... S/N3696501~
42 0027103020 MACHINE SCREW ............................... 1 ..........
43 0601823732 RELAY;LY2DC24V ................................. 1 .......... S/N6396501 TO3699126
0601827655 RELAY;LY2DDC24V .............................. 1 .......... S/N369501~
0601823109 SOCKET;PTF08A ................................. 1 .......... S/N369501~
PYCA1 HOLDER ............................................... 1 .......... S/N3696501~;REPLACES 0601824400
44 0027104020 MACHINE SCREW ............................... 2 .......... S/N3696501~
45 0601823706 RELAY;HE1ADC24V ............................. 1 .......... S/N3696501~
46 0027104010 MACHINE SCREW ............................... 2 .......... S/N3696501~
47 0601815402 TERMINAL BOARD .............................. 1 .......... S/N3696501~
48 0027104020 MACHINE SCREW ............................... 2 .......... S/N3696501~
49 DYN110654000024 CONTROLLER ...................................... 1 .......... S/N3701662~;REPLACES 0602202598
50 DYNT11200 SPEED SENSOR .................................. 1 .......... S/N3701662~;REPLACES 0602120498
51 0027104020 MACHINE SCREW ............................... 4 .......... S/N3701662~
52 0601840009 RHEOSTAT;RA20A2SE502BJ .............. 1 .......... S/N3701662~
53 C3262600004 BRACKET ............................................. 1 .......... S/N3701662~
54 0017106015 HEX. HEAD BOLT ................................. 1 .......... S/N3701662~
Control Box and Panel up to S/N1337562 Cont. Panel S/N1337563~ Cont. Box S/N1337563~
