DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 97
DCA-220SSK — ENGINE & RADIATOR ASSY.
ENGINE & RADIATOR ASSY. S/N1337563 TO3690734
NO PART NO PART NAME QTY. REMARKS
1 C1924200024 ENGINE ...................................................... 1 ............ KOMATSU S6D125E-2
1-1 6125817032 ELEMENT, AIR CLEANER .......................... 1 ............ REPLACES 0602040156
1-2 6002111231 CARTRIDGE, OIL FILTER .......................... 1 ............ REPLACES 0602041146
1-3 6003118293 CARTRIDGE, FUEL FILTER ....................... 1 ............ REPLACES 0602042146
1-4 6004111151 CARTRIDGE, CORROSION RESISTOR ..... 1 ............ REPLACES 0602045143
1-5 0602040678 DUST SENSOR; ......................................... 1 ............ REX018126
2 8185112004 ENGINE FOOT 1
3 0010118060 HEX. HEAD BOLT 2
4 0030018000 HEX. NUT 2
5 0040018000 LOCK WASHER 2
6 0041218000 PLAIN WASHER 4
7 0605000011 RUBBER SUSPENSION 2
8 0030016000 HEX. NUT 4
9 0040016000 LOCK WASHER 4
10 6252619720 RADIATOR ................................................... 1 ............ REPLACES 0602011946
11 6152619170 RUBBER SHEET ......................................... 2 ............ REPLACES 0605000490
12 0010112050 HEX. HEAD BOLT 4
13 0030012000 HEX. NUT 4
14 0040012000 LOCK WASHER 4
15 0041212000 PLAIN WASHER 8
16 8195123104 BRACKET, RADIATOR 2
17 0017112025 HEX. HEAD BOLT 2
18 0017110025 HEX. HEAD BOLT 2
19 6152621520 RADIATOR HOSE ....................................... 1 ............ REPLACES 0602014513
20 6152611531 RADIATOR HOSE ....................................... 1 ............ REPLACES 0602014641
21 0726120911 RADIATOR HOSE ....................................... 1 ............ REPLACES 0602014541
22 0728100809 HOSE BAND ............................................... 6 ............ REPLACES 0602014067
23 0728100909 HOSE BAND ............................................... 2 ............ REPLACES 0602014056
24 0728100197 HOSE BAND ............................................... 2 ............ REPLACES 0602014058
25 3972054104 DRAIN JOINT 1
26 3972054304 PACKING 1
27 C9601000104 DRAIN JOINT 1
28 0017108025 HEX. HEAD BOLT 2
29 0131508000 NIPPLE 1
30 0603325017 VALVE 1
