DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 151
AUTOMATIC OIL FEEDER ASSY. UP TO S/N1337562
NO PART NO PART NAME QTY. REMARKS
1 8195591103 OIL TANK 1
0810105104 CAP, OIL TANK 1
2 0132000000 PLUG 1
3 01120825 HEX. HEAD BOLT ...................... 4 ......... REPLACES 0017108025
4 0130200000 STREET ELBOW 1
5 0602211212 SOLENOID VALVE 1
6 8185524504 BRACKET, SOLENOID VALVE 1
7 0011305100 HEX. HEAD BOLT ...................... 2 ......... REPLACES 0017105012
8 011606025 HEX. HEAD BOLT ...................... 2 ......... REPLACES 0017106025
9 0605511090 OIL LEVEL REGULATOR 1
10 012210035 HEX. HEAD BOLT ...................... 2 ......... REPLACES 0010010035
11 0805531204 BUSHING 1
12 0805531304 HOSE JOINT 4
13 4542025004 HOSE JOINT 1
14 3475512004 HOSE JOINT 1
15 3475006304 PACKING 1
16 0193101600 HOSE 1
17 0193101600 HOSE 1
18 0191600270 HOSE 1
19 0605515000 HOSE BAND 4
20 0605515098 HOSE BAND 2
21 7432051504 HOSE JOINT 1
22 0197301200 HOSE 1
23 0605515014 HOSE BAND 1
DCA-220SSK — AUTOMATIC OIL FEEDER ASSY.
