DCA-220SSK — PARTS AND OPERATION MANUAL (STD)— REV. #3 (06/05/01) — PAGE 125
DCA-220SSK — ACTUATOR ASSY.
ACTUATOR ASSY. S/N3690735~
NO PART NO PART NAME QTY. REMARKS
1 DYNC11024000024 ACTUATOR ...................................................... 1 ........ REPLACES 0602150091
2 DYNC182 LEVER ............................................................. 1 ........ REPLACES 0602211090
3 C1356200004 BRACKET, ACTUATOR 1
4 0012310030 HEX. HEAD BOLT 4
5 0010306035 HEX. HEAD BOLT 4
0207006000 HEX. NUT 4
0040006000 LOCK WASHER 4
0041206000 PLAIN WASHER 4
6 0602211091 ROD 1
7 0602180190 BALL JOINT 2
8 0602211092 HEX. NUT 2
9 0010106025 HEX. HEAD BOLT 1
0207006000 HEX. NUT 1
0041206000 PLAIN WASHER 4
10 0010106025 HEX. HEAD BOLT 1
0207006000 HEX. NUT 1
0041206000 PLAIN WASHER 1
