e) Number of resident dither patterns and number of registrable dither

patterns: Byte 56

Indicates the number of internal dither patterns and the number of dither
patterns that can be downloaded.

B'nnnnXXXX': Number of internal dither patters (upper 4 bits)
B'XXXXnnnn': Number of dither patterns that can be downloaded (lower 4

bits)

The scanner returns X'48'.

f)

Number of resident gamma patterns and number of registrable gamma
patterns: Byte 57

B'nnnnXXXX': Number of internal gamma patterns (upper 4 bits)

B'XXXXnnnn': Number of gamma patterns that can be downloaded (lower

4 bits)

The scanner returns X'38'.

g) Image processing function: Bytes 58 and 59

Indicates the supported image processing functions.

Byte

bit

Description

58

1XXXXXXX

b

X1XXXXXX

b

XX1XXXXX

b

XXX1XXXX

b

XXXX1XXX

b

XXXXX1XX

b

XXXXXX1X

b

XXXXXXX1

b

Black and white reversal
Automatic I (automatic monochrome: DTC)
Automatic II (simple automatic monochrome)
Edge detection
Edge highlighting
Image area separation
Mirror image
Unique white level

59

1XXXXXXX

b

X1XXXXXX

b

XX1XXXXX

b

XXX1XXXX

b

XXXX1XXX

b

XXXXX1XX

b

XXXXXX1X

b

XXXXXXX1

b

Subwindow
Error distribution
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved

The scanner returns X'0140' if the image processing option is not installed.
The scanner returns X'FFC0' if the image processing option is installed.

4 $ 42
