CHAPTER 3CONFIGURATION

3.1

Dimensions

3.2

Circuit Configuration

3.3

Carrier Fixing Bracket Removal

3.4

Power Switch

3.5

Indication Panel Functions

3.1

Dimensions

Figure 3.1 (1) shows the dimensions of M3096GX.

Figure 3.1 (2) shows the dimensions of M3093GX/DG.
