A.4 Grounding Color Area
The color of the shaded area shown in Figure A.3 should be paper grounding color
(white) or drop>out color. If not, select the ™photograph∫ on the operator panel when
reading.
Figure A.3 Grounding color area
3
Main scanning direction
Subscanning
direction
Grounding color
(white) or drop>
out color area
Lead of reading
(Unit : mm)
432 (M3096GX)
355 (M3093GX/DG)
297 (M3096GX/DG)
216 (M3093GX)
Front>side or
Back>side.
*1 If the black area exists in the vicinity of grounding color area, be careful of the
white level following algorithm setting. (See Appendix F)
A $ 8
