4.4.8
SET SUBWINDOW command
The following table shows the normal sequence of the SET SUBWINDOW command
when used with this scanner.
Step
Bus phase
Initiator operation
¨Æ
Target operation
1
BUS FREE
Verifies bus free
2
ARBITRATION
Obtains bus>usage
right
3
SELECTION
Selects target
Æ
Drives BSY signal
4
MESSAGE OUT
Selects logical unit
Æ
5
6
COMMAND
DATA OUT
Specifies SET
SUBWINDOW
(CDB)
Specifies
subwindow data
Ж
Ж
Sets subwindow
7
STATUS
¨
Reports GOOD status
8
MESSAGE IN
¨
Reports message
(Command Complete)
Releases BSY signal
9
BUS FREE
4 $ 74
