f DTC mode: byte 30
X©20π is set when the power is turned on.
This byte is valid when the IPC>2 or IPC>2D is installed, and byte 3E is
X©40π.
7
0
6
0
5 4 3 2 1 0
LSB MSB
Binary data when the threshold equals video
data to be binary>coded. (*1)
0 : Output binary data is ™1∫ (Black)
1 : Output binary data is ™0∫ (White)
Noise removing of 2¥2 matrix
0 : OFF
1 : ON
Noise removing of 3¥3 matrix
0 : OFF
1 : ON
Noise removing of 4¥4 matrix
0 : OFF
1 : ON
Noise removing of 5¥5 matrix
0 : OFF
1 : ON
Enables the noise removing bits (bits 1>4
when this bit is active).
0 : ON
1 : OFF
(Dynamic threshold mode setting)
*1 When this bit is ™0∫, the output video data is black if the gradation of the video
data is equal to or larger than threshold. When this bit is ™1∫, the output video
data is white if the gradation of the video data is equal to or larger than
threshold.
4 $ 69
