FUJITSU M3093DG User Manual
Page 29
Look at the bottom of the scanner to find the carrier fixing bracket.
Remove the screw, and remove the carrier fixing bracket from position . Then
install the carrier fixing bracket at position .
ADF
Upper
(Viewed from below)
Carrier bracket
(position during
operation)
Carrier bracket
(position during
transportation)
Note:
When the scanner is transported, be sure that the carrier fixing bracket is
inposition .
