- Minimum X resolution: Bytes E and F
Indicates the minimum resolution in the horizontal scanning direction.
The scanner returns following value.
Scanner Without IPC option With IPC option
M3096GX
M3093GX
M3093DG X'0064' (100 dpi)
X'00C8' (200 dpi)
X'0032' (50 dpi)
- Minimum Y resolution: Bytes 10 and 11
Indicates the minimum resolution in the vertical scanning direction.
The scanner returns following value.
Scanner Without IPC option With IPC option
M3096GX
M3093GX
M3093DG X'0064' (100 dpi)
X'00C8' (200 dpi)
X'0032' (50 dpi)
- Standard resolution: Bytes 12 and 13
As shown in the table below, this parameter specifies the bits that correspond
to the resolutions that can be specified.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 12 60 75 100 120 150 160 180 200
Byte 13 240 300 320 400 480 600 800 1200
The scanner returns following value.
Scanner Without IPC option With IPC option
M3096GX
M3093GX
M3093DG X'29D4'
X'01D0'
X'FFFE'
4 $ 34
