Page 351: 16 appendix, 1 mechanical overview, 1 front side
RX900 S1
Maintenance Manual
351
16
Appendix
16.1
Mechanical overview
16.1.1 Front side
Figure 238: RX900 S1 front side
For detailed information on connectors see "PRIMERGY RX900 S1 Server -
Operating manual".
Pos. Component
Pos. Component
1
Hard disk drives / dummy
modules #0 - #7, see
5
Control panel
2
ID card
6
Video connector
3
Local service display
7
Optical drive
4
3x USB connectors
/
0
1
2
4
5
3
/
