270 Maintenance Manual RX900 S1
Baseboard
14.4 Installing the TPM
14.4.1 Required tools
● Starting and completing the task:
– key for the rack doors (if applicable)
– Phillips Ph2 screw driver
● Installing the TPM:
– Phillips Ph0 screw driver
14.4.2 Starting the task
Ê Perform the following procedures:
1. "Opening the rack door" on page 40
2. "Shutting down the server" on page 41
3. "Sliding the server out of the rack" on page 42
4. "Opening the server" on page 44
5. Remove the PCI Riser, see "Expansion cards and BBU" on page 105
Authorized personnel
Authorized specialist personnel can carry out replacement tasks for
integral server components. Ask you local Fujitsu service center for
more detailed information.
V
CAUTION!
Procedures indicated as "Authorized personnel only“ must be
done by Fujitsu service personnel or technicians trained by
Fujitsu for doing these tasks. Please note that unauthorized
interference with the system will void the warranty and exempt the
manufacturer from all liability.
