RX900 S1 Maintenance Manual 187
Main memory
9.1.7 Inserting the air duct in the slot (if applicable)
Only applicable for 4 and 6 CPUMEMR configurations.
Figure 110: Inserting the air duct
Ê Insert the air duct in the CPUMER slot (1) as follows:
– 4 CPUMEMR configuration: slot 6
– 6 CPUMEMR configuration: slot 8
Ê Lock the air duct by pushing down the handles (1).
9.1.8 Completing the task
Ê Perform the following procedures to complete the task:
1. "Closing the server" on page 47
2. "Mounting the server in the rack" on page 49
3. "Bringing the server back to operation" on page 51
4. "Closing the rack door" on page 51
