Figure 3-21 rx3600 Power Button
Power Button
3. Start the operating system. For more information see the operating system documentation.
Powering Off the Server
Power off the server using the following methods:
•
iLO 2 MP PC command
• Power button
Powering Off the Server Using the iLO 2 MP
To power off the server using the iLO 2 MP, follow these steps:
1. Gracefully shut down the operating system. For more information see the operating system
documentation.
2. Initiate a console session and access the MP Main Menu.
3. Enter CM to enable command mode.
4. Use the remote power control command with the graceful shutdown option.
5. Enter OFF to power off the server, and enter YES when prompted to confirm the action.
IMPORTANT: The main dc voltage is now removed from the system; however, ac voltage
for standby power is still present in the server.
6. Unplug all power cables from the receptacles on the rear panel of the server.
Powering Off the Server Manually
To manually power off the server, follow these steps:
• A momentary push on the power button will gracefully shut down the operating system.
For more information see the operating system documentation.
IMPORTANT: The main dc voltage is now removed from the system; however, ac voltage
for standby power is still present in the server.
Core I/O Card Configuration
This section provides information on core I/O cards that need to be configured during installation.
This section addresses the following topics:
Core I/O Card Configuration 95
