Table 5-17 Memory Subsystem Events that Light Diagnostic Panel LEDs
Notes Source Cause IPMI Events Diagnostic
LEDs
A voltage on the
memory expander is
out of range (likely
too low) BMC Voltage on memory
board is inadequate. Type 02h, 02h:07h:03h
VOLTAGE_DEGRADES_TO_NON_RECOVERABLE Memory
Carrier
Light all DIMM LEDs
in rank 0 of cell 0 SFW No memory DIMMs
installed in slot 0 of cell
0. Type E0h, 208d:04d
MEM_NO_DIMMS_INSTALLED DIMMs
Either EEPROM is
misprogrammed or
this DIMM is
incompatible SFW A DIMM has a serial
presence detect (SPD)
EEPROM with a bad
checksum. Type E0h, 172d:04d
MEM_DIMM_SPD_CHECKSUM DIMMs
Memory rank is about
to fail or
environmental
conditions are causing
more errors than
usual WIN
Agent This memory board is
correcting too many
single-bit errors. Type E0h, 4652d:26d
WIN_AGT_PREDICT_MEM_FAIL DIMMs
Table 5-18 Memory Subsystem Events that May Light Diagnostic Panel LEDs
Notes Source Cause IPMI Events Diagnostic
LEDs
SFW Unable to clear the
platform error logs in the
CEC. Type E0h, 189d:26d
MEM_ERR_LOG_FAILED_TO_CLEAR Processor
Carrier
SFW Selftest of CEC multibit
error signaling has failed. Type E0h, 181d:26d
MEM_ECC_MBE_SIGNAL_TST_FAILED Processor
Carrier
SFW The CEC failed the
register test. Type E0h, 160d:26d
MEM_BIB_REG_FAILURE Processor
Carrier
SFW System firmware (SFW)
was unable to clear the
platform error logs on the
CEC. Type E0h, 187d:26d
MEM_ECC_MBE_SIGNAL_TST_FAILED Processor
Carrier
SFW The error registers in the
CEC failed to clear. Type E0h, 190d:26d
MEM_ERR_REG_CLEAR_FAILURE Processor
Carrier
SFW The CEC memory
controller failed the
register test. Type E0h, 208d:26d
MEM_MC_REG_FAILURE Processor
Carrier
Voltage wholly
contained on the
memory carrier has
failed. BMC Memory card voltage
error. Type 02h, 02h:07h:06h
VOLTAGE_NON_RECOVERABLE Memory
Carrier
The failing DIMM
quad will be
deallocated. SFW An SDRAM is failing on
the DIMM. Type E0h, 4000d:26d
MEM_CHIPSPARE_DEALLOC_RANK DIMMs
SFW DIMM type is not
compatible with current
DIMMs. Type E0h, 174d:26d
MEM_DIMM_TYPE_INCOMPATIBLE DIMMs
SFW Detected a fatal error in
the DIMM serial presence
detect (SPD). Type E0h, 173d:26d
MEM_DIMM_SPD_FATAL DIMMs
162 Troubleshooting
