Page 169
Table 5-24 I/O Card Events that May Light Diagnostic Panel LEDs (continued)
Notes
Source
Cause
IPMI Events
Diagnostic
LEDs
SFW
PCIe link failed to train
Type E0h, 7346d
CC_IODISC_LBA_LINK_TRAIN_ERR
I/O card
SFW
PCIe link is not
running at maximum
capable bandwidth
Type E0h, 7356d
IO_PCIE_LINK_SUBOPTIMAL
I/O card
and list the PCI slot-rope-ACPI paths.
Table 5-25 PCI/PCI-X Slot-Rope-ACPI Paths
Logical ACPI Path
OLARD
Physical Rope #
Physical Slot #
Acpi(HWP0002,PNP0A03,0)/Pci(1 |0)
Acpi(HWP0002,PNP0A03,0)/Pci(1 | 1)
Acpi(HWP0002,PNP0A03,0)/Pci(1 | 2)
Acpi(HWP0002,PNP0A03,0)/Pci(2 | 0)
Acpi(HWP0002,PNP0A03,0)/Pci(2 | 1)
Acpi(HWP0002,PNP0A03,0)/Pci(2 | 2)
No
0
XX
Slow core iLO 2 MP at 33MHz.
Acpi(HWP0002,PNP0A03,400)/Pci(1 | 0)
No
8
1
Fast core storage at 66 MHz.
Acpi(HWP0002,PNP0A03,400)/Pci(2 | 0)
Acpi(HWP0002,PNP0A03,400)/Pci(2 | 1)
No
8
2
Fast core LAN at 66 MHz.
Acpi(HWP0002,PNP0A03,700)/Pci(1 | 0)
Yes
12, 13, 14 & 15
3
Public, single at 266 MHz.
Acpi(HWP0002,PNP0A03,300)/Pci(1 | 0)
Yes
4, 5, 6 & 7
4
Public, single at 266 MHz.
Acpi(HWP0002,PNP0A03,600)/Pci(1 | 0)
Yes
10 & 11
5
Public, single at 133 MHz.
Acpi(HWP0002,PNP0A03,200)/Pci(1 | 0)
Yes
2 & 3
6
Public, single at 133 MHz.
Acpi(HWP0002,PNP0A03,500)/Pci(1 | 0)
Yes
9
7
Public, shared at 66 MHz.
Acpi(HWP0002,PNP0A03,500)/Pci(2 | 0)
Yes
9
8
Public, shared at 66 MHz.
Acpi(HWP0002,PNP0A03,100)/Pci(1 | 0)
Yes
1
9
Public, shared at 66 MHz.
Acpi(HWP0002,PNP0A03,100)/Pci(2 | 0)
Yes
1
10
Public, shared at 66 MHz.
Table 5-26 PCI/PCI-X/PCIe Slot-Rope-ACPI Paths
Logical ACPI Path
OLARD
Physical Rope
#
Physical Slot #
Acpi(HWP0002,PNP0A03,0)/Pci(1|*)
No
0
XX
Slow core iLO 2 MP at
33MHz.
Acpi(HWP0002,PNP0A03,0)/Pci(2|*)
No
0
XX
Core I/O USB
Common I/O Backplane
169
