Table 5-24 I/O Card Events that May Light Diagnostic Panel LEDs
Notes Source Cause IPMI Events Diagnostic
LEDs
O/S does not boot. The
system displays the
following EFI error
message: “I/O
configuration
exceeded” SFW A non hot plug I/O
slot’s power
consumption increases
the total I/O power
consumption beyond
the supported limit Type E0h, 4658d:26d
IO_PCI_POWER_OVERLOAD_ERR I/O card
The following EFI
warning message
displays: “Failed I/O
slot(s) deconfigured” SFW Insufficient power to
power on a
hot-pluggable PCI-X
slot. Type E0h, 137d:26d
IO_NOT_ENOUGH_POWER_ERROR I/O card
Either a card or a slot
problem. Reseat the
card. SFW PCI slot standby power
failed. Type E0h, 147d:26d
IO_SLOT_STANDBY_POWER_ERROR I/O card
Either a card or a slot
problem. Reseat card
first. SFW PCI-X hot-pluggable
controller failed. Type E0h, 131d:26d
IO_HOT_PLUG_CTRL_FAILED I/O card
Remove any
unsupported I/O cards.
Move an I/O card to an
unused PCI slot. SFW PCI bus walk (I/O
discovery) resources
have been exceeded. Type E0h, 139d:26d
IO_PCI_MAPPING_TOO_BIG I/O card
SFW Found an invalid
PCIXCAP value. Type E0h, 148d:26d
IO_UNKNOWN_PCIXCAP_VAL I/O card
SFW PCIXCAP sampling
error. Type E0h, 141d:26d
IO_PCIXCAP_SAMPLE_ERROR I/O card
SFW Expected I/O host
bridge (LBA) is
missing. Type E0h, 123d:26d
IO_CHECK_LBA_MISSING_ERR I/O card
SFW Expected I/O host
bridge (LBA) is
deconfigured. Type E0h, 619d:26d
IO_CHECK_LBA_DEConFIG_ERR I/O card
SFW I/O LBA clear error
failed. Type E0h, 133d:26d
IO_LBA_CLEAR_ERR_FAILED I/O card
SFW I/O SBA clear error
failed Type E0h, 144d:26d
IO_SBA_CLEAR_ERR_FAILED I/O card
SFW PCI-X slot power on
error. Type E0h, 146d:26d
IO_SLOT_POWER_on_ERROR I/O card
SFW PCI-X slot has an
incorrect default power
state. Type E0h, 145d:26d
IO_SLOT_POWER_DEFAULT_ERROR I/O card
SFW I/O host bridge (LBA)
is inaccessible because
rope reset failed to
complete. Type E0h, 136d:26d
IO_LBA_RESET_ERROR I/O card
SFW PCI clock DLL error. Type E0h, 130d:26d
IO_DLL_ERROR I/O card
SFW I/O rope reset failed to
complete. Type E0h, 143d:26d
IO_ROPE_RESET_ERROR I/O card
168 Troubleshooting
