HP INTEGRITY RX3600 - Manual (Page 71)

NOTE: The number in parenthesis indicates the order in which the quads are loaded.
Table 3-6 24-DIMM Memory Carrier Loading Examples
Memory Carrier Side 1 Memory Carrier Side 0 Quad Slot IDs Quad Number
Example 1
2 GB (2) 2 GB (1) 0A 0B 0C 0D 0
1 GB (4) 1 GB (3) 1A 1B 1C 1D 1
512 MB (6) 512 MB (5) 2A 2B 2C 2D 2
Example 2
1 GB (2) 2 GB (1) 0A 0B 0C 0D 0
1 GB (3) 512 MB (4) 1A 1B 1C 1D 1
512 MB (5) 2A 2B 2C 2D 2
Example 3
1 GB (2) 2 GB (1) 0A 0B 0C 0D 0
512 MB (3) 1A 1B 1C 1D 1
512 MB (4) 2A 2B 2C 2D 2
Example 4
512 MB (2) 2 GB (1) 0A 0B 0C 0D 0
512 MB (3) 512 MB (5) 1A 1B 1C 1D 1
512 MB (4) 512 MB (6) 2A 2B 2C 2D 2
Installing Memory
IMPORTANT: You must pull the ac power plugs on the server every time you modify the
DIMMs. If you do not pull the ac power plugs, the system does not display the correct DIMM
information.
To install memory, follow these steps:
1. Unlatch the cover release lever on the top cover and remove the memory carrier assembly
cover. See
“Removing the Memory Carrier Assembly Cover” (page 57) .
NOTE: You do not need to fully remove the top cover to service this component; however,
the top cover release lever must be open.
2. Remove the memory carrier assembly. See “Removing the Memory Carrier Assembly”
(page 65) .
Installing Additional Components 71
