2 System Specifications
This chapter provides the system specifications for the HP Integrity rx3600 server.
This chapter addresses the following topics:
• “Server Specifications” (page 47)
• “Dimensions and Values” (page 48)
• “Grounding” (page 48)
• “Electrical Specifications” (page 48)
• “Physical and Environmental Specifications” (page 49)
Server Specifications
Table 2-1 lists the server specifications for the HP Integrity rx3600.
Table 2-1 Server Specifications
Specification Component
rx3600 with PCI/PCI-X/PCIe IOBP rx3600 with PCI/PCI-X IOBP
One or two Itanium dual-core processors:
• 1.4 GHz/12 MB cache
• 1.6 GHz/18 MB cache
• 1.42 GHz/12 MB cache
• 1.67 GHz/24 MB cache Processors
8-DIMM memory carrier or 24-DIMM memory carrier
Supported DDR2 DIMM sizes:
• 512 MB
• 1 GB
• 2 GB
• 4 GB Memory
One to eight hot-pluggable SAS hard drives. Disk drives
Two private PCI-X 66 MHz slots. PCI slots
Eight Public slots:
• Two PCI-X slots, 66 MHz
• Two PCI-X slots 133 MHz
• Four PCIe, x8 Eight public PCI-X slots:
• Four PCI-X slots, 66 MHz
• Two PCI-X slots, 133 MHz
• Two PCI-X2 slots, 266 MHz
• Eight port SAS core I/O card (PCI-X)
• Eight port SAS core I/O card with RAID
(PCI-X)
• Eight port SAS core I/O card with RAID (PCIe)
• Eight port SAS core I/O card with RAID able
to connect to external storage (PCIe)
• Eight port SAS core I/O card (PCI-X)
• Eight port SAS core I/O card with RAID
(PCI-X)
SAS core I/O
Options
Two GigE LAN ports. LAN core I/O
Two serial ports, two USB 2.0 ports, one 10 Base-T/100 Base-T LAN port, and one optional VGA
port. Management
core I/O
One DVD or DVD+RW drive Optical device
One 1200 watt power supply, 1+1 redundancy with second power supply. Power supply
Server Specifications 47
