Table 6-2 PCI/PCI-X/PCIe I/O Paths
EFI Device Path HP-UX Device
Path Location as
viewed from
rear of chassis Function
Associated with
Path Slot
Acpi(HWP0002,PNP0A03,400)/Pci(1|*) 0/4/1/* Left-most slot (
nearest to
power supply) SAS core I/O
card 1
Acpi(HWP0002,PNP0A03,400)/Pci(2|*) 0/4/2/* 2nd from left Dual port
Gigabit LAN
(core I/O LAN)
1
2
Acpi(HPQ0002,PNP0A08,600)/Pci(0|0)/Pci(0|0)/Pci(1|0)/Pci(0|*) 0/6/0/0/0/0/1/0/0/* 3rd from left I/O PCIe x8
(switched with
slot 4)
Optional SAS
core I/O card 3
Acpi(HPQ0002,PNP0A08,600)/Pci(0|0)/Pci(0|0)/Pci(0|0)/Pci(0|*) 0/6/0/0/0/0/0/0/0/* 4th from left I/O PCIe x8
(switched with
slot 3)
Optional SAS
core I/O card 4
Acpi(HPQ0002,PNP0A08,700)/Pci(0|0)/Pci(0|*) 0/7/0/0/0/* 5th from left I/O PCIe x8 5
Acpi(HPQ0002,PNP0A08,300)/Pci(0|0)/Pci(0|*) 0/3/0/0/0/* 6th from left I/O PCIe x8 6
Acpi(HWP0002,PNP0A03,200)/Pci(1|*) 0/2/1/* 7th from left I/O 133 MHz
64-bit PCI-X card 7
Acpi(HWP0002,PNP0A03,500)/Pci(1|*) 0/5/1/* 8th from left I/O 133 MHz
64-bit PCI-X card 8
Acpi(HWP0002,PNP0A03,100)/Pci(1|*) 0/1/1/* 9th from left I/O with 66 MHz
64-bit PCI-X card
(shared with slot
10) 9
Acpi(HWP0002,PNP0A03,100)/Pci(2|*) 0/1/2/* 10th from left (
nearest to core
I/O board) I/O with 66 MHz
64-bit PCI-X card
(shared with slot
9) 10
Acpi(HWP0002,PNP0A03,0)/Pci(1|*) 0/0/1/* Right most
special slot Core I/O iLO 2
MP Core
I/O
board
Acpi(HWP0002,PNP0A03,0)/Pci(2|*) 0/0/2/* Right most
special slot Core I/O USB Core
I/O
board
Acpi(HWP0002,PNP0A03,0)/Pci(4|*) 0/0/4/* Right most
special slot Core I/O VGA
(optional) Core
I/O
board
1 The Core I/O LAN may be in slot 10 depending upon the configuration.
Shared Slots
Shared slots have card compatibility restrictions. If one of the shared slots is occupied, the card
added to the second slot is limited by the configuration of the occupied slot. If the new card has
a slower capability than the current bus configuration, it fails. If the new card has a faster capability
than the current bus configuration, it only runs at the slower bus mode and frequency of the
current bus configuration.
The following are common configuration scenarios for cards that use shared slots. These examples
also apply to slots nine and ten because they are shared (both use a common bus).
Removing and Replacing a Hot-Pluggable PCI/PCI-X/PCIe Card 197
