4. If the activity LED on a disk drive does not illuminate during the boot cycle, the disk drive
may be installed incorrectly or its lightpipes may be damaged.
Check the lightpipe on the disk drive as follows:
a.
Remove the disk drive.
b. Inspect the lightpipes for damage. If a lightpipe is damaged, contact HP.
CAUTION: The lightpipes are fragile. Be careful not to damage them when you inspect
them or when you reinsert the disk drive.
c. Replace the disk drive.
d. Power on the server. Determine whether the LED illuminates during the boot cycle. If
it does not, contact HP.
LAN LEDs
There are LAN LEDs on the rear bulkhead of the LAN HBA in PCI-X slot 2 of the HP Integrity
rx3600 server.
HBA Bulkhead LAN LEDs
There are two 1 Gb LAN ports on the LAN HBA bulkhead. These are LAN A and LAN B.
Table 5-29 lists the 1 Gb LAN A interface provides three LEDs on the LAN bulkhead.
Table 5-29 LAN A Connector LEDs
State Color Location LAN LED
None None Top Not used
The 1000 Mb/s ethernet protocol and twisted-pair wiring is
enabled. Blinking
amber 2nd from top 1000Mb
No link Off
The 100 Mb/s with ethernet protocol and twisted-pair wiring
is enabled. Blinking
green 2nd from bottom 100Mb
No link Off
The activity LED is enabled. Blinking
green Bottom Activity
No activity Off
Table 5-30 lists the 1 Gb LAN B interface provides two LEDs on the LAN bulkhead.
Table 5-30 LAN B Connector LEDs
Description Color Location LED
The 1000 MHz with ethernet protocol and twisted-pair wiring
is enabled. Yellow Upper left Speed (upper
left)
The 100 MHz with ethernet protocol and twisted-pair wiring
is enabled. Green
No link Off
link is enabled. Green Upper right Link (upper
right)
No link Off
172 Troubleshooting
