Table 3-11 Physical Connection Matrix
Required Connection Components Connection Method
1. Host console
2. RS-232 serial port DB-9F to DB-9F cable
3. Emulation terminal device (for example, a PC, laptop, or ASCII terminal) RS-232 serial port
10/100 LAN cable LAN port
Determining the iLO 2 MP LAN Configuration Method
To access the iLO 2 MP through the iLO 2 MP LAN, the iLO 2 MP must acquire an IP address.
The way the iLO 2 MP acquires an IP address is dependent upon whether DHCP is enabled or
disabled on the server, and if DHCP and DNS services are available to the server. (See
Table 3-12
for possible scenarios.)
Once you have determined the iLO 2 MP access, you must determine how you will configure
the iLO 2 MP LAN in order to acquire an IP address. There are three methods available.
•
DHCP/DNS
• ARP Ping
• RS-232 serial port
Table 3-12 provides all the possible scenarios to consider. Use this table to help you select the
appropriate LAN configuration method to obtain an IP address.
Table 3-12 LAN Configuration Methods
LAN Configuration Method RS-232 Serial Port (MP
LC
command)
DNS DHCP
DHCP No Yes Yes
DHCP or RS-232 serial port Yes Yes Yes
ARP Ping No No No
ARP Ping No Yes No
ARP Ping or RS-232 Yes Yes No
RS-232 serial port Yes No Yes
RS-232 serial port or ARP Ping Yes No No
Cannot set up the LAN. Reconsider your criteria. No No Yes
Once you have determined how you will configure the iLO 2 MP LAN in order to acquire an IP
address, you must configure the iLO 2 MP LAN using the selected method.
Configuring the iLO 2 MP LAN Using DHCP and DNS
DHCP automatically configures all DHCP-enabled servers with IP addresses, subnet masks, and
gateway addresses. All HP Integrity entry class servers with the iLO 2 MP are shipped from the
factory with DHCP enabled.
HP recommends using the DHCP and DNS method to simplify access to the iLO 2 MP.
NOTE: You can use ARP Ping regardless of the status of DHCP unless an IP address has ever
been acquired using DHCP. Once an IP address is assigned using DHCP, ARP Ping is permanently
disabled.
When you use DHCP and DNS, you can connect to the iLO 2 MP by typing the default host name
in your browser rather than an IP address only if the following applies:
Console Setup 85
