Table 5-15 Processor Events that Light Diagnostic Panel LEDs (continued)
Notes Source Cause IPMI Event Diagnostic
LEDs
Power Pod voltage
is out of range ( too
low). BMC Voltage on the FRU is
inadequate. Type 02h, 02h:07h:03h
VOLTAGE_DEGRADES_TO_NON_RECOVERABLE Processors
Voltage on the FRU
is inadequate. BMC Voltage on the FRU is
inadequate. Type 02h, 02h:07h:03h
VOLTAGE_DEGRADES_TO_NON_RECOVERABLE Processor
Carrier
Table 5-16 Processor Events That May Light Diagnostic Panel LEDs
Notes Source Cause IPMI Event Diagnostic
LEDs
SFW Installed processors are not
compatible. Type E0h, 734d:26d
BOOT_CPU_LOADING_ERROR Processors
SFW Processors and/or
termination are out of
order. Type E0h, 2953d:26d
BOOT_CPU_LOADING_ERROR Processors
SFW A logical CPU thread failed
a late self test. Type E0h, 36d:26d
BOOT_CPU_LATE_TEST_FAIL Processors
SFW A logical CPU thread slave
failed to rendezvous. Type E0h, 677d:26d
MC_RENDEZVOUS_SLAVES_FAIL Processors
SFW A CPU core failed the
configuration process. Type E0h, 30d:26d
BOOT_CPU_ConFIG_FAIL Processors
SFW A processor’s fixed core
frequency ratio is
incompatible with the bus
frequency. Type E0h, 790d:26d
BOOT_CPU_BAD_CORE_FIXED_RATIO Processor
SFW A watchdog timer expired
and determined that a
monarch processor is not
responding. Type E0h, 745d:26d
BOOT_FINAL_RENDEZ_WATCHDOG_FAIL Processor
Bad or slow
processor SFW A logical CPU thread
rendezvous failed. Type E0h, 83d:26d
BOOT_RENDEZ_FAILURE Processors
SFW The logical monarch CPU
thread has timed out. Type E0h, 67d:26d
BOOT_MonARCH_TIMEOUT Processors
SFW A logical slave CPU thread
is incompatible with the
logical monarch CPU. Type E0h, 57d:26d
BOOT_INCOMPATIBLE_SLAVE Processors
SFW CPU PAL is incompatible
with the processor. Type E0h, 56d:26d
BOOT_INCOMPATIBLE_ PAL Processor
SFW A processor failed. Type E0h, 34d:26d
BOOT_CPU_FAILED Processors
SFW A logical CPU thread failed
an early self test. Type E0h, 33d:26d
BOOT_CPU_EARLY_TEST_FAIL Processors
Possible badly
seated or failed
processor BMC No physical CPU cores are
present. Type 02h, 25h:71h:80h
MISSING_FRU_DEVICE Processors
Troubleshooting rx3600 Memory
The memory controller logic in the zx2 chip supports three versions of memory expanders. An
eight DIMM memory carrier provides two memory boards that hold two or four memory DIMMs
160 Troubleshooting
