Home > Introduction to Your Machine > Control Panel Overview
Control Panel Overview
4
5
1
2
3
1. Touchscreen Liquid Crystal Display (LCD)
Access menus and options by pressing them on the touchscreen.
From the Home screen, you can access the WiFi setup 1 , Toner level, Settings, Functions, and Secure Print
screens.
The Home screen displays the machine's status when the machine is idle. When displayed, this screen
indicates that your machine is ready for the next command.
1. ( Wireless Status ) 1
Press to configure wireless settings.
For certain models, the Home screen displays the wireless status when the optional Wireless Module is
installed.
If you are using a wireless connection, a four-level indicator on the Home screen displays the current
wireless signal strength.
0 Max
• If you see displayed as the Wireless Status, press it to select a wireless connection method or
edit an existing wireless connection.
2. IP Address
If the IP Address setting in the Screen Settings menu is turned on, your machine's IP Address appears on
the Home screen.
3. [Secure Print]
Press to access the Secure Print option.
1 For certain models, the wireless network connection can be used only when the optional Wireless Module is installed.
