PLANET MGSW-28240F - Manual (Page 234)

Command Guide of MGSW-28240F
uni OAM PDU is transmitted with unicast MAC. The MAC is taken from peer MEP MAC database.
mep-id Peer MEP-ID for unicast DM. The MAC is taken from peer MEP MAC database.
Peer MEP-ID value
last-n The last N dalays used for average last N calculation. Min value is 10.
The last N value
Default:
0
Usage Guide:
To configure Delay Measurement of MEP
Example:
To configure Delay Measurement of MEP 1 as below table.
Switch# configure terminal
Switch (config)# mep 1 dm 5 rdtrp interval 10 last-n 10
4.2.120 mep dm ns
Command:
mep dm ns
mep Maintenance Entity Point
The MEP instance number.
dm Delay Measurement
ns Nano Seconds
Default:
us
Usage Guide:
To configure Delay Measurement of MEP
Example:
To configure Delay Measurement unit (ns) of MEP 1 as below table.
-234-
