Inserting the megaraid 320 card in a pci slot, N in, Figure 2.1 – Avago Technologies MegaRAID SCSI 320-0 (520-0 CH) User Manual

Page 28

background image

2-4

Hardware Installation

Copyright © 2003-2008 by LSI Corporation. All rights reserved.

Figure 2.1

Inserting the MegaRAID 320 Card in a PCI Slot

Bracket Screw

64-Bit Slots (5 V)

Press Here

Edge of

Motherboard

Press Here
