6-16 Chapter 6

Figure 6-14 Configured Wan Call Destinations

NOTE: If no permanent WAN Call Destinations have been

defined for this interface, an error message will be
displayed.

9) Highlight the desired WAN Call Destination, then press .

Press until you are prompted to save IPX Bind Parameters.
Answer Yes to save and exit.

10) Press again to return to the

Internetworking Configuration

menu.

To initiate any of the newly defined bindings on the WAN interface,
issue the REINITIALIZE SYSTEM command at the server/router
console OR bring down the server/router and restart.

To implement changes to an existing binding to a WAN interface, you
must issue the UNBIND IPX FROM command at the
server/router console, and then bring down and restart the server/router.

What’s Next?

After configuring the Frame Relay WAN connections, refer to chapter 7 to:

Configure the X.25 WAN connections.
