Emulex DCP_link - Manual (Page 89)

6-12 Chapter 6
NOTE: If you have not configured any Network Interfaces
before attempting to configure a WAN Call
Destination, you receive this message:
WAN network interfaces must be configured
before WAN Call Destinations may be created.
5) Select EMX F Relay as the wide area medium. The Frame Relay Call
Destination Configuration menu is displayed:
Figure 6-7 Call Destination Configuration
6) Interface Name : Press to select the Network interface that has
been defined for EMX F Relay.
7) Circuit Type : Permanent, the default, is the only option available.
8) DLCI Number : Press to select the local DLCI (circuit number)
entered in the Network Interfaces screen.
9) After defining all the necessary parameters, press and select Yes
to save the changes to the Frame Relay WAN Call Destination
Configuration.
