Hardware Installation 3-11
RS-423 Cable Assembly
TDA
RDA
RTSA
CTSA
DSRA
CDA
RCA
TCA
DTRA
SG
RGND
TBD
RDB
RTSB
CTSB
DSRB
CDB
RCB
TCB
DTRB
RGND
MODE0
MODE1
MODE2
MODE3
Figure 3-3
1
2
14
3
16
4
19
5
13
6
22
8
10
9
17
12
15
20
23
7
11
18
21
24
25
SHELL
1
2
14
3
16
4
19
5
13
6
22
8
10
9
17
12
15
20
23
7
11
18
21
24
25
SHELL
J1
MICRO-D25 FEMALE
P1
DB25 MALE
Figure 3-6 Emulex Part #PT1011211-01
