Hardware Installation 3-5

− RS232 8-port breakout cable for DCP386i and DCP486e adapter

(80-pin),
Emulex part no. PA1011236-01.

RS-422/X.21 Cabling

For RS-422/X.21 conversion, you will need a set of eight X.21 conversion
cables at the end of the 8-port breakout cable. These are available from
Emulex Sales Support.

− RS422 8-port breakout cable for DCP386i and DCP486e adapter

(100-pin),
Emulex part no. PT1011205-01

Note: Be sure to securely screw in all cables to avoid any

loose connections.
