2-10 Chapter 2
PORT 2 PORT 1
Figure 2-9 DTE Settings for the V.35 Mode
PORT 2 PORT 1
Figure 2-10 DCE Settings for the V.35 Mode
What’s Next?
After configuring the DCP286i adapter, refer to chapter 3 to:
† Install the DCP286i adapter in your computer.
† Attach cable.
