Frame Relay Configuration 6-11
NOTE: If a WAN Call Destination has not been configured,
the list will be empty (as pictured above).
3) Press to configure a new WAN Call Destination.
The prompt New Call Destination Name allows you to enter a name of
up to 47 alphanumeric characters for the new WAN Call Destination.
Figure 6-5 Configure Wan Call Destinations
The WAN Call Destination name entered here is used in other menu
options when a WAN Call Destination name needs to be identified. You
should use a descriptive name, such as the name of the remote
destination or a branch office or store number.
4) Enter a name for the new WAN Call Destination, then press .
A list of supported wide area media is displayed.
Figure 6-6 Choose a Supported Wide Area Medium
These are media types that have been generated through the INETCFG
Network Interfaces menu. If you have not yet configured a Frame Relay
interface, then Frame Relay is not available for WAN Call Destinations.
