3-18 Chapter 3
V.35 Null Modem Cable
FG
RTS
CTS
TDA
TDB
RDA
RDB
RCA
RCB
TCA
TCB
ETC-A
ETC-B
DSR
CD
DTR
SG
SHELL
A
C
D
P
S
R
T
V
X
Y
AA
U
W
E
F
H
B
SHELL
DCP PORT
V.35 MALE
TERMINAL OR
OR OTHER DTE
V.35
FG
RTS
CTS
TDA
TDB
RDA
RDB
RCA
RCB
TCA
TCB
ETC-A
ETC-B
DSR
CD
DTR
SG
A
C
D
P
S
R
T
V
X
Y
AA
U
W
E
F
H
B
Figure 3-13 (Not Supplied by Emulex)
